E
BOTTOM COWLING ASS’Y (FT9.9D)
BRKT
7-16
EXPLODE DIAGRAM
REMOVAL AND INSTALLATION CHART
Step
r
t
y
u
i
o
p
a
s
d
f
g
h
Q’ty
2
2
1
1
1
1
1
1
1
1
1
1
2
Service points
M6 x 12 mm
Reverse the disassembly steps for assembly.
Procedure/Part name
Bolt
Bracket 1
Bolt
Bracket 2
Bolt
Plate
Collar
Cowling lock lever ass’y
Washer
Collar
Bolt
Shift cable bracket base (for MH/EH models)
Damper
