B. Cross machining control (G110/G111)
Axis control of HD2 side by HD1 side or that of HD1 side by HD2 side is referred to as cross
machining control. Specify after G110 an axis address and the HD number controlling the axis.
(Refer to 4-6-2 1. A, 4-6-2 1. D and 4-6-2 2. B for the sample program.)
Programming format
G110 X_ Y_ Z_; .................... Cross machining control axis and HD number are specified.
G111; ..................................... Cross machining control axis specified by G110 is returned
to normal control (not cross machining).
Example: Operation at HD1 side
G110 X2; Changed to X-axis of HD2
G00 X10. Z10.; X of HD2 moves to 10, Z of HD1 moves to 10.
G110 Z2; Changed to Z-axis of HD2
G00 X20. Z20.; X of HD2 moves to 20, Z of HD2 moves to 20.
G110 X1 Z1; Changed to X-axis and Z-axis of HD1
G00 X30. Z30.; X of HD1 moves to 30, Z of HD1 moves to 30.
Specify the Z-axis for the lower turret as follows:
Example:
G110 Z2; Selection of the lower turret’s Z-axis
G00 Z100.; All the Z-axial commands between G110 and
G111 are processed
as those for the lower turret.
G111; Cancellation of G110
Specify the C-axis on the 2nd headstock side as follows:
Example:
G110 C2; Selection of the 2nd headstock’s C-axis
G00 C45.123.; All the C-axial commands between G110 and
G111 are processed
as those for the 2nd headstock side.
G111; Cancellation of G110
1: Axis controlled by HD1
2: Axis controlled by HD2
