YAMAZAKI MAZAK VORTEX i Series User Manual

SUPPLEMENT 5
5-71
3. M-code (Spindle)
A. Turning spindle start of forward rotation/start of forward rotation/rotation stop
1. Command
Programming format
Ss M203
Turning spindle 1 Start of forward rotation
Ss M204
Turning spindle 1 Start of backward rotation
M205
Turning spindle 1 Rotation stop
Ss M303
Turning spindle 2 Start of forward rotation
Ss M304
Turning spindle 2 Start of backward rotation
M305
Turning spindle 2 Rotation stop
Function
This function code rotates the turning spindle No.1 forward/ backward. (M203/M204)
This function code stops rotation of the turning spindle No.1. (M205)
This function code rotates the turning spindle No.2 forward/ backward. (M303/M304)
This function code stops rotation of the turning spindle No.2. (M305)
Code value
Description
Unit
Setting range
Omit
s
Surface speed (G96)
m/min
feet/min
0 to 99999
Possible
Spindle speed (G97)
min
-1
0 to 99999
Possible
B. Milling spindle start of forward rotation/start of forward rotation/rotation stop
1. Command
Programming format
Ss M03
Start of forward milling spindle rotation
Ss M04
Start of backward milling spindle rotation
M05
Stop of milling spindle rotation
Function
This function code rotates the milling spindle forward/ backward. (M3/ M4)
This function code stops the milling spindle. (M5)
Code value
Description
Unit
Setting range
Omit
s
Spindle speed
min
-1
0 to 99999
Possible
C. Turning spindle 1 c-axis connect/milling mode select
1. Command
Programming format
M200
Turning spindle 1 C-axis connect/Milling mode select
M300
Turning spindle 2 C-axis connect/Milling mode select
Function
This function code connects the turning spindle No.1 to the C-axis
and changes the mode to milling. (M200)
This function code connects the turning spindle No.2 to the C-axis
and changes the mode to milling. (M300)
D. Turning spindle C-axis disconnect/turning mode select
1. Command
Programming format
M202
Turning spindle 1 C-axis disconnect/turning mode select
M302
Turning spindle 2 C-axis disconnect/turning mode select
Function
This function code disconnects the C-axis from the turning spindle No.1
and changes the mode to turning. (M202)
This function code disconnects the C-axis from the turning spindle No.2
and changes the mode to turning. (M302)
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
Serial No. 294060
