YAMAZAKI MAZAK VORTEX i Series User Manual

MACHINE INFORMATION 2
2-23
2. INTEGREX i-S
A. On turning/milling
[mm/min (in/min) or deg/min]
Machine specification
X
Y
Z
B
C1
W
C2
i-100S
-
8000
(314)
8000
(314)
8000
(314)
5000
STD:
36000
BT:
10800
8000
(314)
36000
i-100BARTAC-S
-
i-200S
1000U
36000
1500U
i-300S
1500U
2500U
i-400S
1500U
2500U
B. On milling (During geometry compensation)
[mm/min (in/min) or deg/min]
Machine specification
X
Y
Z
B
C1
W
C2
i-100S
-
40000
(1574)
40000
(1574)
40000
(1574)
14400
199800
40000
(1574)
199800
i-100BARTAC-S
-
i-200S
1000U
1500U
i-300S
1500U
2500U
i-400S
1500U
2500U
3. INTEGREX i-ST
A. On turning/milling
[mm/min (in/min) or deg/min]
Machine specification
X1
Y
Z1
B
C1
W
i-100ST
-
8000
(314)
8000
(314)
8000
(314)
5000
STD:36000
BT:10800
8000
(314)
i-100BARTAC-ST
-
i-200ST
1500U
36000
i-300ST
1500U
i-400ST
1500U
Machine specification
X2
Z2
C2
i-100ST
-
8000
(314)
8000
(314)
36000
i-100BARTAC-ST
-
i-200ST
1500U
i-300ST
1500U
i-400ST
1500U
Serial No. 294060
