3 NC COMMAND
3-1 Programming Format
3-1-1 Words and addresses
Table 3-1 Type and format of words
Item
Address
Command range
Program No.
O
1 to 99999999
Sequence No.
N
1 to 99999
Preparatory function
G
0 to 999.9
Moving axis
X, Y, Z … 
B, C ... 
0 to ±99999.9999 (mm)
0 to ±9999.99999 (in)
0 to ±99999.9999 (°)
Auxiliary axis
I, J, K
0 to ±99999.9999 (mm)
0 to ±9999.99999 (in)
0 to ±99999.9999 (°)
Dwell
X
0 to 99999.999
P
0 to 99999999
Feed
F
0 to 200000.0000 (mm)
0 to 20000.00000 (in)
Fixed cycle
R, Q, P, L
0 to ±99999.9999 (mm)
0 to ±9999.99999 (in)
0 to ±99999.9999 (°)
Tool offset
H, D
0 to 999
Miscellaneous function
M
0 to 999
Spindle function
S
0 to 99999
Tool function
T
0 to 99999999
No.2 miscellaneous function
A
0 to 99999999
Subprogram
P
1 to 99999999
Variables number
#
1 to 999999
1. The number of digits in the words is checked by the maximum number of digits of the
addresses.
2. When data with decimal point is used for address for which decimal input is not available,
decimal figures will be ignored.
3. If the number of integral digits exceeds the specified format, an alarm will result.
4. If the number of decimal digits exceed the specified format, the excess will be rounded.
5. If “0” is set at the head of number, it is skipped.
e.g. G01 = G1, M06 = M6
6. The maximum number of characters per line (per 1 block) is 248.
7. The above table shows the range of number for each command. If the command exceeds
these, the alarm generates. And, do not command a value which will exceed the machine
limit value (axis stroke, rotating speed ...etc).
