4-4-3 3-axis machining program
This section explains 3-axis machining programs.
1. Inclined-plane machining
This section explains 3-axis machining program using the G68.2 inclined plane machining mode.
A. Sample program
(3-axis machining_Inclined plane)
G109L1
M901
M200
M212
G0G90G94G55G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
T001T00M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B0.0
G97S1000M03
G10.9X0
M08
G61.1
M108M212
G68.2 P1X10.0 Y0 Z0 I-60.0 J0 K0
G53.1
M107M210
G90 G43 X30.0 Y90.0 Z20.0 H1
G1 Z15.0 F500
Y-90.0
(Machining contour)
Y-90.0
Z3.
G0 Z50.0
G69
G64
M05
M09
G91G28X0
G28Z0
G28Y0
M108
G90G53B0
M30
Preparation motion for machining
 G109L1: Upper turret selection
 M901: HD1 spindle selection
 M200: C-axis connect/Milling mode select
 M212: C-axis unclamping
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T001M06: Tool change (TNo.01)
 B-axis positioning
 G97S1000: Rotation speed 1000 min
-1
 M03: Milling spindle forward rotation
 G10.9X0: Radius data input mode
 M08: Flood coolant ON
End motion for machining
 M05: Stop of milling spindle rotation
 M09: All coolants stop
 Each axis positioning to zero return
 M30: Reset and rewind
Machining motion
 G61.1: Geometry compensation
 M108M212: Rotation axes unclamping
 G68.2: Inclined-plane machining
 P1: Using roll, pitch, and yaw angles
 G53.1: Tool-axis direction control
 M107M210: Rotation axes clamping
 G43H**(P0): Tool length offset
 (Machining contour)
 G69: Inclined-plane machining OFF
 G64: Geometry compensation OFF
Machining contour
