B. Using lower turret and HD1 for milling
This section explains how to make program (Lower turret - HD1- Milling).
1. Sample programs
G109L1
G91G28X0
G28Z0
G28Y0
G28B0
M950
M951
M952
M30
G109L2
M901
M200
G0G90G94G55G97
G40G49G80G67G69
G91G28X0
G28Z0
M950
T001000
G91G28X0
G28Z0
G97M03S3000
G10.9X0
M51
M951
G90G43G0X-150.Z450.0 H1
M250
X-200.
G1Z440.F0.25
X-190.
G90G0X-150.
G40
M05
M952
M09
G91G28X0
G28Z0
M30
Machining
(Lower turret - HD1- Milling)
jiku
Preparation motion for machining
 G109L2: Lower turret selection
 M901: HD1 spindle selection
 M200: C-axis connect/Milling mode select
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T001000: Tool change (TNo.01 Lower)
 G97S3000: Rotation speed 3000 min
-1
 M03: Milling spindle forward rotation
 G10.9X0: Radius data input mode
 M51: Milling spindle-through coolant ON
Machining motion
End motion for machining
 M05: Stop of milling spindle rotation
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
 G109L1: Upper turret selection
 Each axis positioning to zero return
 M30: Reset and rewind
