MACHINING PROGRAM 4
4-53
5. Relevant M codes of programming for compound machining
M-codes
M-codes
Description
M107
B-axis clamping
M108
B-axis unclamping
M206
Turning spindle 1 Chuck open
M207
Turning spindle 1 Chuck close
M306
Turning spindle 2 Chuck open
M307
Turning spindle 2 Chuck close
M508
Pressing setup
M509
Pressing setup release
M511
Turning spindle synchronized rotation
(master: turning spindle No. 1, slave: turning spindle No. 2)
M512
Turning spindle synchronized rotation
(master: turning spindle No. 2, slave: turning spindle No. 1)
M513
Turning spindle synchronized rotation OFF
M540
TRANSFER mode ON
M541
TRANSFER mode OFF
M562
Balance cut start
M563
Balance cut end
M950 to M997
Waiting Command
A. Chuck open and close (M206/M207/M306/M307)
The chuck open and close M-codes of Turning spindle 1 and 2 shown the following.
(Refer to 4-6-2 2. B for the sample program.)
HD1
HD2
X
Z
M206: Chuck open
M207: Chuck close
M306: Chuck open
M307: Chuck close
M-codes for chuck open and close
