YAMAZAKI MAZAK VORTEX i Series User Manual

4 MACHINING PROGRAM
4-66
D. Using upper turret and HD2 for milling
This section explains how to make program (Upper turret – HD2- Milling).
1. Sample program
G109L1
M902
M300
M312
G0G90G94G54G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
G28B0
M950
T001T002M06
G91G28X0
G28Y0
G28Z0
G110X2Z2
G90G0X0Z-1000.
G111
M108
G90G53B90.
M107
G97M03S3000
G10.9X0
M51
M951
M310M107
G90G43G00X100.Y-7.Z-100.H1
X80.
G287X60.Z-100.R3.Q5.F115.
G80
X80.
G40
M05
M302
M952
M09
G91G28X0
G28Z0
G28Y0
G28B0
M30
G109L2
M950
M951
M952
M30
Machining
(Upper turret – HD2- Milling)
jiku
Preparation motion for machining
 G109L1: Upper turret selection
 M902: HD2 spindle selection
 M300: C-axis connect/Milling mode select
 M312: C-axis unclamping
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T001M06: Tool change (TNo.01)
 G110 to G111: Cross machining control
axis is specified
 Z-1000.: Escape position is specified
 B-axis positioning
 M107: B-axis clamping
 G97S3000: Rotation speed 3000 min
-1
 M03: Milling spindle forward rotation
 G10.9X0: Radius data input mode
 M51: Milling spindle-through coolant ON
Machining motion
End motion for machining
 M05: Stop of milling spindle rotation
 M302: C-axis disconnect/turning mode
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
 G109L2: Lower turret selection
 M30: Reset and rewind
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
