6. G-code (Group07)
A. Tool radius compensation/nose radius compensation
1. Command
Programming format
G41 Xx Yy Dd
(TOOL OFFSET) (Note)
G42 Xx Yy Dd
(TOOL OFFSET) (Note)
G41 Xx Yy
(MAZATROL TOOL DATA) (Note)
G42 Xx Yy
(MAZATROL TOOL DATA) (Note)
Cancellation
G40
Function
Offsetting in any vectorial direction can be done according to the tool radius preselected
using G-codes and D-codes. This function is referred to as tool radius compensation. For
turning tools, moreover, nose radius compensation can be performed according to the
designated direction.
Code value
Description
Unit
Setting range
Omit
G41
To compensate a tool radius (to the left)
G42
To compensate a tool radius (to the right)
x, y
Position of X, Y-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
d
Tool offset number
1 to Maximum offset No.
Note: It depends on the setting of F92 bit7 and F94 bit7 whether TOOL OFFSET or
MAZATROL TOOL DATA is selected.
Data items used
Parameter
Programming
format
F92 bit7
F94 bit7
Tool offset No.
Tool offset No.
0
0
G41/G42 D
Tool Data
(MAZATROL)
NOSE-R/ACT- + OFFSET No.
NOSE-R/ ACT- + ATC- CO.
1
1
G41/G42 T
ATC- CO.
OFFSET No.
0
1
G41/G42 T
Tool offset + Tool Data
Tool offset No. + NOSE-R/ACT-
1
0
G41/G42 D + T
2. Notes
 Successive setting of 22 or more move-free blocks during the compensation mode
may result in excessive or insufficient cutting.
