MACHINING PROGRAM 4
4-71
B. Parallel machining of HD2
This section explains how to make program (HD2- Parallel machining).
1. Sample program
G109L1
M902
M300
M312
G0G90G94G54G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
G28B0
M950
T002T003M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B90.0
M107
G97M03S3000
G10.9X0
M51
M951
M310M107
G90G43G0X100.0Y-7Z-10.0 H1P0
X50.
G1Z-100.R3.F115.
X150.
G40
M952
M05
M302
M953
M09
G91G28X0
G28Z0
G28Y0
G28B0
M30
(HD2- Parallel machining (1/2))
jiku
Preparation motion for machining
 G109L1: Upper turret selection
 M902: HD2 spindle selection
 M300: C-axis connect/Milling mode select
 M312: C-axis unclamping
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T002M06: Tool change (TNo.02)
 B-axis positioning
 M107: B-axis clamping
 S97S3000: Rotation speed 3000 min
-1
 M03: Milling spindle forward rotation
 G10.9X0: Radius data input mode
 M51: Milling spindle-through coolant ON
Machining motion
End motion for machining
 M05: Stop of milling spindle rotation
 M302: C-axis disconnect / turning mode
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
