YAMAZAKI MAZAK VORTEX i Series User Manual

4 MACHINING PROGRAM
4-72
2. Program composition
Program composition element
Command of upper turret
Command of lower turret
Machining motion
Instruction in
Preparation motion
For machining
Lower turret
HD2
Milling
Instruction in
Preparation motion
For machining
HD2
Milling
Machining motion
G109L2
M959
M902
M300
G0G90G94G54G97
G40G49G80G67G69
G91G28X0
G28Z0
M950
T101000
G91G28X0
G28Z0
M03 S3000
G10.9X0
M51
M951
M952
G4X2.
G90G43G0X-180.Z-200.H1
X-150.
G1Z-150.F0.25
X-180.
G0X-200.
G40
M05
M953
M09
G91G28X0
G28Z0
M30
(HD2- Parallel machining (2/2))
jiku
Preparation motion for machining
 G109L2: Lower turret selection
 M902: HD2 spindle selection
 M300: C-axis connect/Milling mode select
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T101000: Tool change (TNo.101 Lower)
 S3000: Rotation speed 3000 min
-1
 M03: Milling spindle forward rotation
 G10.9X0: Radius data input mode
 M51: Milling spindle-through coolant ON
End motion for machining
 M05: Stop of milling spindle rotation
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
Machining motion
Machining
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
Serial No. 294060
