3. Use of any other addresses than P, Q, X, Y, Z, I, J, and K will lead to an alarm (1809
TILTED PLANE CMD FORMAT ERROR).
4. Argument Q can be omitted if Q123 is required.
5. The designation of Q with any other value than enumerated above will lead to an
alarm (1809 TILTED PLANE CMD FORMAT ERROR).
Fixed Cycles
High-speed deep-hole drilling
Synchronous reverse tapping
Note : is G-code used by sample program.
See the programming manual, if you use the other patterns.
Setting fixed-cycle machining data
Set fixed-cycle machining data as follows:
Hole-machining mode (G-code)
See the list of the fixed cycles.
GX_Y_Z_Q_R_P_D_K_I_J(B)_E_H_F_L_
Repeat times
Hole-machining data
Conversion by means of roll, pitch, and yaw angles
Workpiece
coordinate
system
1) Translation of the
system
Feature
coordinate
system
