YAMAZAKI MAZAK VORTEX i Series User Manual

5 SUPPLEMENT
5-10
3. Notes
 One block including more than 128 characters causes an alarm.
 The section from the head of a program to the place where G109 is commanded is
common to HD1 and HD2, or TR1 and TR2.
2. G-code (Group01)
Once this command has been given, the G00 mode will be retained until any other G-code
command that overrides this mode, that is, either G00, G01, G02 or G03 of command group 01
is given.
A. Positioning
1. Command
Programming format
G00 Xx Yy Zz 
Function
Positioning command G00 involves use of a coordinate word. This command positions a
tool by moving it linearly to the ending point specified by a coordinate word.
Code value
Description
Unit
Setting range
Omit
x
Position of X-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
y
Position of Y-axis
mm
in
±99999.9999(mm)
±9999.99999 (in)
Possible
z
Position of Z-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible

Position of additional axis (linear axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
Position of additional axis (rotational axis)
°
±99999.9999 (±359.9999)
Possible
B. Linear interpolation
1. Command
Programming format
G01 Xx Yy Zz Ff
Function
This command moves (interpolates) a tool from the current position to the ending point
specified by a coordinate word, at the feed rate specified with address F. The specified feed
rate acts here as the linear velocity relative to the direction of movement of the tool center.
Code value
Description
Unit
Setting range
Omit
x
Position of X-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
y
Position of Y-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
z
Position of Z-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible

Position of additional axis (linear axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
Position of additional axis (rotational axis)
°
±99999.9999 (±359.9999)
Possible
f
Feed Rates (linear axis)
mm/min
in/min
0 to 200000.0000 (mm)
0 to 20000.00000 (in)
Possible
Feed Rates (rotational axis)
°/min
0 to 200000.0000 (359.9999)
Possible
