YAMAZAKI MAZAK VORTEX i Series User Manual

SUPPLEMENT 5
5-11
C. Circular interpolation
1. Command
Programming format
G02 Xx Yy (Zz) Ii Jj (Kk) Ff
G03 Xx Yy (Zz) Ii Jj (Kk) Ff
G02 Xx Yy (Zz) Rr Ff
G03 Xx Yy (Zz) Rr Ff
Function
Commands G02 and G03 feed the tool along an arc.
Code value
Description
Unit
Setting range
Omit
G02
Circular movement direction CW
G03
Circular movement direction CCW
x
Position of X-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
y
Position of Y-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
z
Position of Z-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
i
Position of arc center (X-axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
j
Position of arc center (Y-axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
k
Position of arc center (Z-axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
f
Feed Rates
mm/min
in/min
0 to 200000.0000 (mm)
0 to 20000.00000 (in)
Possible
r
Radius of the arc
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
D. Helical interpolation
1. Command
Programming format
G17 (G18/G19) G02 (G03) Xx Yy Zz Ii Jj Pp Ff
G17 (G18/G19) G02 (G03) Xx Yy Zz Rr Pp Ff
Function
Command G02 or G03 with a designation for the third axis allows synchronous circular
interpolation on the plane specified by plane-selection command G17, G18 or G19 with the
linear interpolation on the third axis.
Code value
Description
Unit
Setting range
Omit
G17
XY-plane selection
G18
ZX-plane selection
G19
YZ-plane selection
G02
CW
G03
CCW
x, y
Arc ending point coordinates (X, Y-axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Impossible
z
Linear axis ending point (Z-axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Impossible
I, j
Arc center coordinates (X, Y-axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Impossible
r
Arc radius
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Impossible
p
Number of pitches
0 to 9999
Possible (1)
f
Rate of feed
mm/min
in/min
0 to 200000.0000 (mm)
0 to 20000.00000 (in)
