4 MACHINING PROGRAM
4-50
A. Tool function [4-digit T-Code for turret-indexing systems]
Tool function, also referred to as T-code function, is used to designate the tool number. Of a
four-digit integer at address T, upper and lower two digits are respectively used to specify the
tool number and trailing zeros (00).
Use bit 4 of parameter F162 to select the number of digits for the tool function (0 or 1 for 4- or
6-digit T-code).
T 00. ;
Tool ID code
Tool number
Designate the tool ID code with reference to the settings on the TOOL DATA display.
Only one T-code can be included in a block, and the available range of T-codes depends on the
machine specifications. For further details, especially on how to number the actual tools to be
used, refer to the operating manual of the relevant machine.
The T-code can be given with any other commands in one block, and the T-code given together
with an axis motion command is executed, depending upon the machine specifications, in one of
the following two timings:
The T-code is not executed till completion of the motion command, or
The T-code is executed simultaneously with the motion command.
Remark: Instead of zeros, other numerals can be specified as well in the lower two digits
without exercising any influence upon the machine control.
B. Tool function [6-digit T-Code for turret-indexing systems]
This function is also used to designate the tool number. Of a six-digit integer at address T, upper
and lower three digits are respectively used to specify the tool number and trailing zeros (000).
See the above description of the 4-digit T-code for the meaning of the decimal fractions.
The available range of T-codes depends on the machine specifications. For further details, refer
to the operating manual of the relevant machine.
Only one T-code can be included in a block.
Use bit 4 of parameter F162 to select the number of digits for the tool function (0 or 1 for 4- or
6-digit T-code).
T 000. ;
Tool ID code
Tool number
Remark: Instead of zeros, other numerals can be specified as well in the lower three digits
without exercising any influence upon the machine control.
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
