4-3 Preparation Motion for Machining
This section explains “Preparation motion for machining”.
4-3-1 Sample program
This figure shows sample programs for preparation for machining.
Refer to 4-3-2 for more information about each motion.
4-3-2 Preparation for machining
Each motion of “Preparation for machining” is explained 1.-11..
Select the motions to suit machining method
1. Turret selection
Select a turret to use.
As “INTE i series” and “INTE is series” have no lower turret, all machining are selected as upper
turret. So these machines do not require these commands.
G109L1: Upper turret
G109L2: Lower turret
G109L1
M901
M200
M212
G00G90G94 G54G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
T001T002M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B90.0
G97S12000M03
G10.9X0
M08
HD1 Upper turret Milling
G109L1
M901
M202
G00G18G90G95G54G96
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
T001.1T002.15M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B90.0
G92S3000R1
G96S150M204
G10.9X1
M08
HD1 Upper turret Turming
Preparation motion for machining
