YAMAZAKI MAZAK VORTEX i Series User Manual

4 MACHINING PROGRAM
4-64
C. Using lower turret and HD2 for turning
This section explains how to make program (Lower turret – HD2- Turning).
1. Sample program
G109L1
G91G28X0
G28Z0
G28Y0
G28B0
M950
M951
M952
M30
G109L2
M902
M302
G00G18G90G95G54G96
G40G49G80G67G69
G91G28X0
G28Z0
M950
T101000
G91G28X0
G28Z0
G92S2000R1
G96M303S200R1
G10.9X1
M08
M951
G90G43G0X-180.Z-150.0 H1
M250
G91X-150.Z-130.
G1Z-100.F0.25
X-180.
G90G0X-200.Z-150.0
G40
M305
M952
M09
G91G28X0
G28Z0
M30
Machining
(Lower turret – HD2- Turning)
jiku
Preparation motion for machining
 G109L2: Lower turret selection
 M902: HD2 spindle selection
 M302: C-axis disconnect / turning mode
 G95: Feed per revolution
 G96: Constant surface speed control ON
 T101000: Tool change (TNo.101 Lower)
 G92S2000: Spindle speed range setting
 G96S200: Surface speed 200 m/min
 R1: Set the HD2
 M303: Turning spindle2 forward rotation
 G10.9X1: Diameter data input mode
 M08: Flood coolant ON
Machining motion
End motion for machining
 M305: Turning spindle2 Rotation stop
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
 G109L1: Upper turret selection
 Each axis positioning to zero return
 M30: Reset and rewind
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
