MACHINING PROGRAM 4
4-59
Two-process control by one program Separate machining
This function is the two systems can be controlled by a single program.
(It is not necessary to change the parameter when this function is used.)
Note 1: Description in parentheses is not directly relate with machining.
Note 2: (U.T.): These commands are ordered of Upper turret machining.
Note 3: (L.T.): These commands are ordered of Lower turret machining.
G28X0Z0
•
•
G109L1
•
•
M950(U.T.)
•
•
M951(U.T.)
•
•
M30(U.T.)
G109L2
M950(L.T.)
M951(L.T,)
M30(L.T.)
Program
Common
Upper turret
(System 1)
Lower turret
(System 2)
Operation
Start of program
G109L1
(Upper turret)
G109L2
(Lower turret)
Common
M950(U.T.)
M950(L.T.)
M30(U.T.)
Upper turret end
M30(L.T.)
Lower turret end
M951(L.T.)
M951(U.T.)
Note: It is necessary to order
waiting command in
system that does not
processed when order
waiting command (M950
etc) in separate
machining.
