MACHINING PROGRAM 4
4-3
4-2 Programming Composition
This section explains programming composition.
4-2-1 Programming composition
The figure shows program composition which is explained in this manual.
The program consists of three compositions: “Preparation motion for machining”, “Machining
motion”, and “End motion for machining”.
Machining motions are selected from A-E according to machining processes.
Figure. Program composition
Preparation for machining
1. Turret selection
2. Head selection
3. Modal command
4. Home return
5. Tool change
6. Home return after tool change
7. B-axis positioning
8. Spindle rotation command
9. Radius/Diameter data input
10. Coolant command
11. Others
Machining motion
A
Turning
Approach
Turning
Escape
B
Drilling
Approach
Hole
Escape
C
3-axis
Approach
3-axis
operation
machining
Escape
D
4-axis
Approach
4-axis
operMachi
ning
Escape
E
5-axis
Approach
5-axis
Escape
End motion for machining
1. Coolant stop command
2. Rotation stop command
3. Home return
4. Program end
