2-1-4 Input limitation
This section indicates input limitation value of NC.
Input limitation
Axis
Maximum command unit
Minimum command unit
Number of digit after the
decimal point
Linear axes [mm]
±99999.9999
0.0001
4-digit
Linear axes [in]
±9999.99999
0.00001
5-digit
Rotary axes [°]
±99999.9999
0.0001
4-digit
2-1-5 Rotating speed
This section indicates limiting value of rotating speed.
Limitations of the rotating speed of the turning spindle will vary according to the chuck used.
* The values in the table indicate the rotating speed for the standard chuck.
1. INTEGREX i
[min
-1
]
Machine specification
Spindle No. 1
Spindle No. 2
Mill Spindle
(12000min
-1
)
Standard
Mill Spindle
(20000min
-1
)
Option
i-100
-
35 to 6000
-
35 to 12000
35 to 20000
i-150
-
35 to 5000
i-200
1000U
1500U
i-300
1000U
35 to 4000
1500U
2500U
i-400
1000U
35 to 3300
1500U
2500U
Remark: 3000 min
-1
is upper limit value during tapping cycle.
2. INTEGREX i-S
[min
-1
]
Machine specification
Spindle No. 1
Spindle No. 2
Mill Spindle
(12000min
-1
)
Standard
Mill Spindle
(20000min
-1
)
Option
i-100S
-
35 to 6000
35 to 6000
35 to 12000
35 to 20000
i-100BARTAC-S
-
35 to 2000
i-200S
1000U
35 to 5000
35 to 5000
1500U
i-300S
1500U
35 to 4000
35 to 4000
2500U
i-400S
1500U
35 to 3300
35 to 3300
2500U
Remark: 3000 min
-1
is upper limit value during tapping cycle.
