YAMAZAKI MAZAK VORTEX i Series User Manual

SUPPLEMENT 5
5-5
E. Return to second reference point
1. Command
Programming format
G30 Pp Xx Yy Zz 
Function
The returning to the second, third, or fourth reference point can be programmed by setting
“G30 P2 (P3, P4)”.
Code value
Description
Unit
Setting range
Omit
p
Reference point
(P2: Second reference point
P3: Third reference point
P4: Fourth reference point)
2, 3, 4
Possible (2)
x, y, z
Interm. point (X, Y, Z-axis)
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible

Interm. point (Additional axis)
mm
in
°
±99999.9999 (mm)
±9999.99999 (in)
±99999.9999 (°)
Possible
F. Skip function
1. Command
Programming format
G31 Xx Yy Zz Ff
Function
During linear interpolation by G31, when an external skip signal is inputted, the feed will
stop, all remaining commands will be cancelled and then the program will skip to the next
block.
Code value
Description
Unit
Setting range
Omit
x, y, z
Position of X, Y, Z-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
f
Feed Rates
mm/min
in/min
0 to 200000.0000 (mm)
0 to 20000.00000 (in)
Possible
2. Notes
 An asynchronous feed rate commanded previously will be used as feed rate. If an
asynchronous feed command is not given previously and if Ff is not commanded, the
value set by the parameter K41 will be used as the feed rate. F-modal command data
will not be updated by the F-command given in the G31 block.
 Setting this command code during tool nose/tool radius compensation results in an
alarm.
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
Serial No. 294060
