5 SUPPLEMENT
5-72
E. Spindle speed attainment check
1. Command
Programming format
M250
Function
Confirms whether the specified spindle speed has been attained.
4. M-code (Clamp)
A. B-axis clamping/unclamp
1. Command
Programming format
M107
B-axis clamping
M108
B-axis unclamping
Function
This function code activates the clamping mechanism of the B-axis. (M107)
This function code deactivates the clamping mechanism of the B-axis. (M108)
B. Turning spindle C-axis clamping/unclamping
1. Command
Programming format
M210
Turning spindle 1 C-axis clamping
M211
Turning spindle 1 C-axis braking
M212
Turning spindle 1 C-axis unclamping
M310
Turning spindle 2 C-axis clamping
M311
Turning spindle 2 C-axis braking
M312
Turning spindle 2 C-axis unclamping
Function
This function code activates the C-axis clamping mechanism to clamp the C-axis when the
turning spindle No. 1 is connected to the C-axis. (M210)
This function code activates the C-axis braking mechanism to brake the C-axis when the
turning spindle No. 1 is connected to the C-axis. (M211)
This function code deactivates the C-axis clamping mechanism and braking mechanism
when the turning spindle No. 1 is connected to the C-axis. (M212)
This function code activates the C-axis clamping mechanism to clamp the C-axis when the
turning spindle No. 2 is connected to the C-axis. (M310)
This function code activates the C-axis braking mechanism to brake the C-axis when the
turning spindle No. 2 is connected to the C-axis. (M311)
This function code deactivates the C-axis clamping mechanism and braking mechanism
when the turning spindle No. 2 is connected to the C-axis. (M312)
C. Turning spindle chuck open/close
1. Command
Programming format
M206
Turning spindle 1 Chuck open
M207
Turning spindle 1 Chuck close
M306
Turning spindle 2 Chuck open
M307
Turning spindle 2 Chuck close
Function
This function code opens the chuck of the turning spindle No. 1. (M206)
This function code closes the chuck of the turning spindle No. 1. (M207)
This function code opens the chuck of the turning spindle No. 2. (M306)
This function code closes the chuck of the turning spindle No. 2. (M307)
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
Serial No. 294060
