YAMAZAKI MAZAK VORTEX i Series User Manual

4 MACHINING PROGRAM
4-4
4-2-2 Method of making program
This section explains how to make a machining program.
First command steps 1. to 10. (or 11.) of Preparation for machining. Select A-E in Machining
motion. Command steps 1. to 4. In End motion for machining.
See 4-6 besides 4-3, 4-4 and 4-5 for Programming for Compound Machining.
4-6 explains method of making one program for multi-process, waiting command and transfer
operation.
2.Head selection
1.Turret selection
3.Modal command
4.Home return
5.Tool change
6.Home return
after tool change
7.B-axis
positioning
8.Rotation command
9.Radius/Diameter
10.Coolant
G109L1
M901
M200
M212
G00G90G94 G54G97
G40G49G80G67G69
G91 G28X0
G28Z0
G28Y0
T001T002.15M06
G91 G28X0
G28Z0
G28Y0
M108
G90G53B90.0
G97S12000M03
G10.9X0
M08
Preparation motion for machining
4-3-2 1.
4-3-2 2.
4-3-2 3.
4-3-2 4.
4-3-2 5.
4-3-2 6.
4-3-2 7.
4-3-2 10.
4-3-2 9.
4-3-2 8.
