5 SUPPLEMENT
5-22
B. Tool length offset in tool-axis direction
1. Command
Programming format
G43.1 Xx Yy Zz Hh
(TOOL OFFSET) (Note)
G43.1 Xx Yy Zz
(MAZATROL TOOL DATA) (Note)
Cancellation
G49
Function
The preparatory function G43.1 refers to offsetting the tool, in whatever direction it may be
inclined three-dimensionally, in the direction of its axis through the length offset amount. In
the G43.1 mode the tool length offsetting is always performed in the tool-axis direction, in
accordance with the motion command for a rotational axis concerned, through the relevant
offset amount.
Code value
Description
Unit
Setting range
Omit
x, y, z
Position of X, Y, Z-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
h
Tool offset number
1 to Maximum offset No.
Note: It depends on the setting of F93 bit3 and F94 bit7 whether TOOL OFFSET or
MAZATROL TOOL DATA is selected.
Data items used
Parameter
Programming format
F94 bit7
F93 bit3
Tool offset
Tool offset No.
0
0
G43.1 H
Tool Data (MAZATROL)
LENGTH
1
1
T + G43.1
LENGTH + OFFSET No.
LENGTH + LENG CO.
T + G43.1 H
OFFSET No.
LENG CO.
1
0
G43.1 H
Tool offset + Tool
Tool offset No. + LENGTH
0
1
T+ G43.1 H
2. Notes
 The execution of a G49 command does not cause any axis motion.
