YAMAZAKI MAZAK VORTEX i Series User Manual

2 MACHINE INFORMATION
2-10
Machine specification
Wmax
Wmin
C
Holder end
Spindle
center
Without
steady rest
With
steady rest
Unit
mm
(in)
deg
mm
(in)
mm
(in)
i-100S
-
0
(0)
-903
(-35.55)
-
±360
[Cycloid
type]
80
(3.15)
-400
(-15.75)
i-100BARTAC-S
-
i-200S
1000U
-1066
(-41.97)
170
(6.69)
-490
(-19.29)
1500U
-1574
(-61.96)
i-300S
1500U
2500U
-2175
(-85.63)
i-400S
1500U
-1574
(-61.97)
2500U
-2175
(-85.63)
e-420H-S
1500U
2
(0.08)
-1370
(-53.94)
-1054
(-41.50)
249
(9.80)
-715
(-28.15)
3000U
-3078
(-121.18)
-2762
(-108.74)
e-500H-S
1500U
5
(0.20)
-1524
(-60.00)
-
300
(11.81)
-850
(-33.46)
3000U
-3048
(-120.00)
-2458
(-96.77)
e-670H-S
3000U
-1005
(-39.57)
4000U
-
-3209
(-126.34)
