YAMAZAKI MAZAK VORTEX i Series User Manual

2 MACHINE INFORMATION
2-12
D. INTEGREX e-V/i-V
Machine specification
Xmax
Xmin
Ymax
Ymin
Zmax
Zmin
Bmax
Bmin
Unit
mm
(in)
mm
(in)
mm
(in)
deg
e-1060V
-
0
(0)
-1525
(-60.039)
5
(0.197)
-1055
(-41.535)
0
(0)
-1345
(-52.952)
120
-30
e-1250V/8
Single
-1875
(-73.818)
0
(0)
-1250
(-49.213)
2-pallet
e-1550V
-
-1550
(-61.023)
e-1600V/10
Single
-2165
(-85.236)
-1600
(-62.992)
2-pallet
-2315
(-91.142)
e-1850V
-
-3055
(-120.275)
-1850
(-72.834)
-1800
(-70.866)
i-500V/5
2-pallet
-1100
(-43.307)
-800
(-31.496)
-900
(-35.433)
i-630V/6
Single
-1425
(-56.102)
-1050
(-41.338)
-1050
(-41.338)
2-pallet
+
–
+
–
–
+
Y
Home Position
Y
center
Y
stroke
Z
stroke
Z
Home Position
X
Home Position
Spindle center
X stroke
B
stroke
+B
stroke
-B
stroke
Holder
end
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
Serial No. 294060
