5 SUPPLEMENT
5-78
Function
Code
G61.1+G05P2
commanded in
leftward code mode
Leftward code
commanded in
G61.1+G05P2 mode.
Inclined-plane machining ON
G68.2

-
Inclined-plane machining (by specifying tool-axis
direction) ON
G68.3

-
Inclined-plane machining OFF
G69

-
Finishing cycle
G270
-
-
Longitudinal roughing cycle
G271
-
-
Transverse roughing cycle
G272
-
-
Compound thread-cutting cycle
G276
-
-
Fixed cycle OFF
G80

-
Face driling cycle
G283
-
-
Face tapping cycle
G284
-
-
Face boring cycle
G285
-
-
Fixed cycle A (Longitudinal turning cycle)
G290
-
-
Threading cycle
G292
-
-
Fixed cycle B (Transverse turning cycle)
G294
-
-
Fixed cycle (Chamfering cutter 1, CW)
G71.1
-
-
Fixed cycle (Chamfering cutter 2, CCW)
G72.1
-
-
Fixed cycle (High-speed deep-hole drilling)
G73
-
-
Fixed cycle (Reverse tapping)
G74
-
-
Fixed cycle (Boring 1)
G75
-
-
Fixed cycle (Back spot facing)
G77
-
-
Fixed cycle (Spot drilling)
G81
-
-
Fixed cycle (Tapping)
G84
-
-
Fixed cycle (Reaming)
G85
-
-
Fixed cycle (Back boring)
G87
-
-
Absolute data input
G90

-
Incremental data input
G91

-
Inverse time feed
G93


Constant surface speed control ON
G96
-
-
Constant surface speed control OFF
G97
-
-
Feed per minute (asynchronous)
G94


Feed per revolution (synchronous)
G95
-
-
Subprogram call
G98
-
-
Return to main program
G99
-
-
Polar coordinate input ON
G16
-
-
Polar coordinate input OFF
G15
-
-
Selection between diameter and radius data input
Diameter data input mode OFF
G10.9 X0
-
-
Selection between diameter and radius data input
Diameter data input mode ON
G10.9 X1
-
-
