YAMAZAKI MAZAK VORTEX i Series User Manual

5 SUPPLEMENT
5-84
Function
Code
G68 commanded
in leftward code
mode
Leftward code
commanded in
G68 mode.
Inclined-plane machining (by specifying tool-axis
direction) ON
G68.3
-
-
Inclined-plane machining OFF
G69


Finishing cycle
G270
-
-
Longitudinal roughing cycle
G271
-
-
Transverse roughing cycle
G272
-
-
Compound thread-cutting cycle
G276
-
-
Fixed cycle OFF
G80


Face driling cycle
G283
-

Face tapping cycle
G284
-

Face boring cycle
G285
-

Fixed cycle A (Longitudinal turning cycle)
G290
-
-
Threading cycle
G292
-
-
Fixed cycle B (Transverse turning cycle)
G294
-
-
Fixed cycle (Chamfering cutter 1, CW)
G71.1
-

Fixed cycle (Chamfering cutter 2, CCW)
G72.1
-

Fixed cycle (High-speed deep-hole drilling)
G73
-

Fixed cycle (Reverse tapping)
G74
-

Fixed cycle (Boring 1)
G75
-

Fixed cycle (Back spot facing)
G77
-

Fixed cycle (Spot drilling)
G81
-

Fixed cycle (Tapping)
G84
-

Fixed cycle (Reaming)
G85
-

Fixed cycle (Back boring)
G87
-

Absolute data input
G90


Incremental data input
G91


Inverse time feed
G93


Constant surface speed control ON
G96


Constant surface speed control OFF
G97


Feed per minute (asynchronous)
G94


Feed per revolution (synchronous)
G95


Subprogram call
G98


Return to main program
G99


Polar coordinate input ON
G16
-
-
Polar coordinate input OFF
G15

-
Selection between diameter and radius data input
Diameter data input mode OFF
G10.9 X0

Selection between diameter and radius data input
Diameter data input mode ON
G10.9 X1


Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
