B. Program composition
C. Parameter setting
Parameter setting
Parameter
bit
Standard
Setting
Description
F114
3
1
1
Moving axes by using G49 (tool length offset cancel) in G43 (tool
length offset) mode Invalid
G61.1
M108
G90G53Bb
G90G00Cc
M107
G90G43G00XxYyZzHh
G17G90G00XxCc
G12.1
G01G41(G42)DdXxCcFf
(Machining pattern)
G40
G13.1
G64
Machining motion of program composition -Polar coordinate interpolation-
--- Geometry compensation
--- B-axes unclamping
--- B-axis positioning
--- C-axis positioning
--- B-axes clamping
--- Tool length offset
--- XC-plane selection
--- Polar coordinate interpolation
ON
--- Tool radius compensation
--- Machining pattern
--- Tool radius compensation OFF
--- Polar coordinate interpolation
OFF
--- Geometry compensation OFF
G41/42
G40
Tool radius
compensation
G12.1
G13.1
Polar coordinate
interpolation
The figure below indicates setting
of each mode
G61.1
G64
Geometry compensation
When G17 XC is commanded, X and C
move to the specified positions.
Instruction in
preparation motion
for machining
Instruction in
machining motion
Upper turret
HD1
milling
Polar coordinate interpolation
Tool radius compensation
Geometry compensation
Program composition element
