YASKAWA E-S Series

11.1 List of Parameters
11.1.2 List of Parameters
11-7
11
Parameter List
Pn40D 2
Second Stage
Notch Filter Q
Value
50 to 1,000 0.01 70
Immedi-
ately
Tuning page 8-35
Pn40E 2
Second Stage
Notch Filter Depth
0 to 1,000 0.001 0
Immedi-
ately
Tuning page 8-35
Pn460
2
Notch Filter
Adjustment
Selections
0000h to
0101h
− 0101h
Immedi-
ately
Tuning page 8-15
Pn502 2
Rotation
Detection Level
1 to 10,000
1 min
-1
30
Immedi-
ately
Setup page 5-15
Pn503 2
Speed
Coincidence
Detection Signal
Output Width
0 to 100
1 min
-1
30
Immedi-
ately
Setup −
Pn506 2
Brake
Reference-SERVO
OFF Delay Time
0 to 50 10 ms 0
Immedi-
ately
Setup −
Pn507 2
Brake Reference
Output Speed
Level
0 to 10,000
1 min
-1
100
Immedi-
ately
Setup −
Pn508 2
SERVO OFF-
Brake Reference
Waiting Time
10 to 100 10 ms 50
Immedi-
ately
Setup −
Pn51E 2
Position Deviation
Overflow Warning
Level
10 to 100 1% 100
Immedi-
ately
Setup
page 10-15
Pn520 4
Position Deviation
Overflow Alarm
Level
1 to
1,073,741,823
1 refer-
ence unit
25600
Immedi-
ately
Setup
page 8-5,
page 10-3
Pn526 4
Position Deviation
Overflow Alarm
Level at SERVO
ON
1 to
1,073,741,823
1 refer-
ence unit
25600
Immedi-
ately
Setup page 8-5
Pn528 2
Position Deviation
Overflow Warning
Level at SERVO
ON
10 to 100 1% 100
Immedi-
ately
Setup page 8-5
Pn529 2
Speed Limit Level
at SERVO ON
0 to 10,000
1 min
-1
10000
Immedi-
ately
Setup page 8-5
Pn52B 2
Overload Warning
Level
1 to 100 1% 20
Immedi-
ately
Setup page 5-28
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Notch Filter Adjustment Selection 1
0
Do not adjust the first stage notch filter automatically during execution of custom
tuning.
1 Adjust the first stage notch filter automatically during execution of custom tuning.
n.X Reserved parameter (Do not change.)
n.X Notch Filter Adjustment Selection 2
0
Do not adjust the second stage notch filter automatically during execution of cus-
tom tuning.
1
Adjust the second stage notch filter automatically during execution of custom tun-
ing.
n.X Reserved parameter (Do not change.)
