YASKAWA E-S Series

11.1 List of Parameters
11.1.2 List of Parameters
11-19
11
Parameter List
PnBC0
2
/INPOSITION
(Positioning
Completion
Output)
Signal Allocation
0000h to
00C2h
− 0000h
After
restart
Setup page 5-13
PnBC1
2
/POUT0
(Program Step
Number Output 0)
Signal Allocation
0000h to
00C2h
− 0010h
After
restart
Setup page 5-14
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Signal Usage Method
0 Turn ON (close) the output when positioning is completed.
1 Turn OFF (open) the output when positioning is completed.
2 Do not use this signal.
n.X Signal Terminal Number
0 Output signal from CN1-18.
1 Output signal from CN1-20.
2 Output signal from CN1-21.
3 Output signal from CN1-22.
4 Output signal from CN1-23.
5 Output signal from CN1-24.
6 Output signal from CN1-25.
7 Output signal from CN1-26.
8 Output signal from CN1-27.
9 Output signal from CN1-28.
A Output signal from CN1-29.
B Output signal from CN1-30.
C Output signal from CN1-31.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output when program step number output 0 is 1.
1 Turn OFF (open) the output when program step number output 0 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
