11.1 List of Parameters
11.1.2 List of Parameters
11-20
PnBC2
2
/POUT1
(Program Step
Number Output 1)
Signal Allocation
0000h to
00C2h
− 0020h
After
restart
Setup page 5-14
PnBC3
2
/POUT2
(Program Step
Number Output 2)
Signal Allocation
0000h to
00C2h
− 0030h
After
restart
Setup page 5-14
PnBC4
2
/POUT3
(Program Step
Number Output 3)
Signal Allocation
0000h to
00C2h
− 0040h
After
restart
Setup page 5-14
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Signal Usage Method
0 Turn ON (close) the output when program step number output 1 is 1.
1 Turn OFF (open) the output when program step number output 1 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output when program step number output 2 is 1.
1 Turn OFF (open) the output when program step number output 2 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output when program step number output 3 is 1.
1 Turn OFF (open) the output when program step number output 3 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
