YASKAWA E-S Series - Page 271

11.1 List of Parameters
11.1.2 List of Parameters
11-21
11
Parameter List
PnBC5
2
/POUT4
(Program Step
Number Output 4)
Signal Allocation
0000h to
00C2h
− 0050h
After
restart
Setup page 5-14
PnBC6
2
/POUT5
(Program Step
Number Output 5)
Signal Allocation
0000h to
00C2h
− 0060h
After
restart
Setup page 5-14
PnBC9
2
/WARN
(Warning Output)
Signal Allocation
0000h to
00C2h
− 0002h
After
restart
Setup page 5-14
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Signal Usage Method
0 Turn ON (close) the output when program step number output 4 is 1.
1 Turn OFF (open) the output when program step number output 4 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output when program step number output 5 is 1.
1 Turn OFF (open) the output when program step number output 5 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output when an error or warning occurs (error/warning status).
1 Turn OFF (open) the output when an error or warning occurs (error/warning status).
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
