11.2 Parameter Recording Table
11-29
Pn200 0000h
Reserved parameter
(Do not change.)
After restart
Pn207 0010h
Position Control Function
Selections
After restart
Pn20E 1
Electronic Gear Ratio
(Numerator)
After restart
Pn210 1
Electronic Gear Ratio
(Denominator)
After restart
Pn217 0
Average Position Reference
Movement Time
Immediately
after the
motor stops
Pn304 500 Jog Speed Immediately
Pn305 100
Soft Start Acceleration
Time
Immediately
Pn306 100
Soft Start Deceleration
Time
Immediately
Pn401 100
First Stage First Torque
Reference Filter Time Con-
stant
Immediately
Pn402 800 Forward Torque Limit Immediately
Pn403 800 Reverse Torque Limit Immediately
Pn404 100
Forward External Torque
Limit
Immediately
Pn405 100
Reverse External Torque
Limit
Immediately
Pn406 800 Emergency Stop Torque Immediately
Pn408 0000h
Torque-Related Function
Selections
*
Pn409 2000
First Stage Notch Filter Fre-
quency
Immediately
Pn40A 70
First Stage Notch Filter Q
Value
Immediately
Pn40B 0
First Stage Notch Filter
Depth
Immediately
Pn40C 2000
Second Stage Notch Filter
Frequency
Immediately
Pn40D 70
Second Stage Notch Filter
Q Value
Immediately
Pn40E 0
Second Stage Notch Filter
Depth
Immediately
Pn460 0101h
Notch Filter Adjustment
Selections
Immediately
Pn502 30 Rotation Detection Level Immediately
Pn503 30
Speed Coincidence Detec-
tion Signal Output Width
Immediately
Pn506 0
Brake Reference-SERVO
OFF Delay Time
Immediately
Pn507 100
Brake Reference Output
Speed Level
Immediately
Pn508 50
SERVO OFF-Brake Refer-
ence Waiting Time
Immediately
Pn51E 100
Position Deviation Over-
flow Warning Level
Immediately
Pn520 25600
Position Deviation Over-
flow Alarm Level
Immediately
Continued on next page.
Continued from previous page.
Parame-
ter No.
Default
Setting
Name
When
Enabled
