YOKOGAWA WT500 User Manual

6-4
IM 760201-01E
• Changing an Element or Wiring Unit
10.
Use the cursor keys to select Element/
Σ
.
11.
Press SET to display the element or wiring unit selection box.
12.
Use the cursor keys to select an element or wiring unit from the list (which starts
with Element1).
13.
Press SET or ESC to confirm the selection. The element number or wiring
unit symbol for the selected element or wiring unit appears along with its
corresponding numeric data in the highlighted area.
• Changing a Harmonic Order
14.
Use the cursor keys to select Order.
15.
Press SET to display the harmonic order selection box.
16.
Use the cursor keys to select a harmonic order.
17.
Press SET or ESC to confirm the selection. The selected harmonic order appears
along with its corresponding numeric data in the highlighted area. This ends the
description of how to change displayed items using the menu.
You do not need to set harmonic orders in the Single List or Dual List displays.
6.2 Changing Numeric Data Display Items
