YOKOGAWA WT500 User Manual

10-6
IM 760201-01E
• Setting Numeric Data Types One by One
8.
Use the cursor keys to select the element or measurement function that you
want to set.
9.
Press SET. If the indicator to the left of the element or measurement function that
you selected lights, its corresponding numeric data will be saved. If the indicator
turns off, its corresponding numeric data will not be saved.
Executing or Canceling the Save Operation
10.
Press ESC to close the List Item dialog box.
11.
Use the cursor keys to select Save.
12.
Press SET to display the Save menu.
13.
Use the cursor keys to select File List.
14.
Press SET to display the File List dialog box.
Selecting a Storage Medium
15.
Use the cursor keys to select the storage medium (displayed using brackets) that
you want to save to.
16.
Press SET to confirm the selection.
Selecting a Directory
(Follow these procedures if the storage medium has directories.)
17.
Use the cursor keys to select the directory (displayed using < >) that you want to
save to.
18.
Press SET to confirm the selection.
The selected storage medium and directory appear in the upper left of the File List
dialog box after “Path=.”
10.3 Saving Setup Parameters, Waveform Display Data, and Numeric Data
