ABB AC 800F

5 AC 800F Functional Description
5-36
The default values for the configuration items are written in braces. They can be
confirmed by pressing the Return key. The following prompt appears:
For each of the following questions, hit <RET> to keep the value in
braces or enter a new value.
Configuring the Ethernet interface
This is only required if
• other nodes are working on the Ethernet together with the AC 800F or Freelance
2000 components (process station, operator station, engineering station) or
• the Ethernet is not stand-alone and is connected to other networks or
• more than 14 AC 800F (special case) are used on the same system bus (see
Sections 3.3.5 and 5.3.1).
Adjusting the Internet address
If not more than 14 AC 800F are working on the Ethernet and there is no connection
to other networks, use the standard address:
Slot E1: 172.16.1.<Coding switch position> (only for positions 1 ... E)
E2: 172.16.16.<Coding switch position> (only for positions 1 ... E)
If other, non-Freelance 2000 nodes are on the same network or if there is a
connection to other networks, contact your network administrator. He will assign an IP
address to your stations.
The following menu items will only appear (for every Ethernet module) if the coding
switch of the respective Ethernet module is set to 0.
For slot E1
Enter first interface IP address: [172.16.1.1]
For slot E2
Enter second interface IP address: [172.16.16.1]
