ABB AC 800F

5 AC 800F Functional Description
5-37
The prompt requests an entry with the form DDD.DDD.DDD.DDD. The entry is made
in decimal numbers (DDD = 0...255). Zeros to the left of the number can be omitted.
Enter for example: 172.16.1.22<RETURN>
The broadcast address 255.255.255.255 and the address 0.0.0.0 are special cases
and cannot be entered by the operator. In case of an invalid entry the Boot Loader
repeats this configuration item.
Adjusting the Subnet Mask
There is a subnet mask for each Internet address. Contact your network administrator
for this mask.
The subnet mask is entered in the same way as the Internet address.
Enter subnet mask: [255.255.240.0]
The subnet mask is entered in the same way as the Internet address.
Adjusting the network type
Here you can set up the type of network. For a 10Base5 or 10Base2 network select
the default setting [1]. Contact your system administrator for the type of network used.
Enter network transmission speed:
1. High (pure Ethernet)
2. Medium (Modem >= 64 KBit)
3. Low (Modem < 64 KBit)
Select: [1]
You should only modify this setting if your Ethernet link is rerouted via
special long distance paths.
Adjusting the default router
This prompt serves for entering the Internet address of a default router for
communication with remote operator stations, if applicable.
Enter default-router IP Address: [0.0.0.0]
