4. Press the SUPPLY ON push button on the door of the control unit to charge
the DC link.
The push button flashes during charging.
The status line of the control panel alternates between Charging
and AuxiliaryOn.
NOTE – After charging has been finished, the following takes place:
• Main circuit breaker closes automatically.
• SUPPLY ON push button lights up permanently.
• Drives with an ARU:
– The ARU is now “ReadyRun”.
• INU 1 and other INUs (if present) are now in status “ARU NotRun”
Alternating display message:
– Charging
– AuxiliaryOn
1 L -> 0.0 rpm
StateINU Charging
MOTOR SP 0.00 rpm
POWER 0.0 kW
1 L -> 0.0 rpm 0
StateINU ReadyRun
MOTOR SP 0.00 rpm
POWER 0.0 kW
1 L -> 4840.0 V 0
StateARU ReadyRun
DC Voltage 4400.0 V
COS PHI 0.2
1 L -> 0.0 rpm 0
StateINU ARU NotRun
MOTOR SP 0.00 rpm
POWER 0.0 kW
