Advanced AF-6600 - Page 100

Version 16.10 AF-6600 AF-5000 Series Install Manual 100
Pin
Function
No tes
15
11-33V DC
Connect to Aircraft Power
16
No Connect
-
17
External Standby In
Optional: Not Commonly Connected
18
Mutual Suppression
Optional: Not Commonly Connected
19
Squat Switch In
Optional: Not Commonly Connected
20
Ident Switch In
Optional: Not Commonly Connected
21
No Connect
-
22
No Connect
-
23
No Connect
-
24
No Connect
-
25
No Connect
-
