Version 16.10 AF-6600 AF-5000 Series Install Manual 148
Pressure Transducer Installation
Firewall Installation using Van’s P/N: VA-168, 3-port manifold mounting block.
Oil Pressure Transducer Installation
Mount the oil pressure transducer in a stationary location. Connect the transducer with aircraft grade hose
and fittings. The proper oil pressure port can be found in the engine manual. The engine must have a
pressure fitting with a restrictor hole in it. The transducer is supplied with 1/8” NPT pipe thread
connections. The Oil Pressure transducer should be connected from the harness to the transducer using the
supplied 3 pin connector. The transducers require +5V power and ground.
SV-EMS Pin Signal Harness Transducer Wire
Pin 18 +5V Power Red/White Red
Pin 17 Ground Black Black
Pin 6 Signal White/Yellow Green
NOTE: The pressure rating (10bar 150psi) can be found stamped on the bottom hex fitting of the
transducer
P/N Pressure Manufacturer Color Termination
41150 0-150 PSI (10 bar) Kavlico Gold/Black Plug
CAUTION: NEVER CONNECT THE PRESSURE TRANSDUCER DIRECTLY TO THE ENGINE.
Fuel Pressure Transducer Installation
Mount the fuel pressure transducer to a stationary location. Connect the transducer with aircraft grade hose
and fittings. The proper fuel pressure connection port can be found in the engine manual. The engine must
have a pressure fitting with a .040” or smaller restrictor hole in it, this prevents fuel pump pulsations
from damaging the transducer and will slow the flow of fuel if a hose were to fail. The transducer is supplied
with 1/8” NPT pipe thread connections. The case of the sender has to be connected to ground. The
Fuel Pressure transducer wire should be connected from the harness to the transducer by crimping a
standard #8 ring terminal to the wire.
SV-EMS Pin Signal Harness Transducer Wire
Pin 18 +5V Power Red/White Red
Pin 17 Ground Black Black
Pin 8 Signal Brown Green
NOTE: The pressure rating can be found stamped on the bottom hex fitting of the transducer
Fuel Injected engines should use the 150 PSI sensor and Carbureted Engine should use the 15 PSI
P/N Pressure Manufacturer Color Terminal
41015 0-15 PSI Kavlico Gold/Black Plug
41150 0-150 PSI Kavlico Gold/Black Plug
