Version 16.10 AF-6600 AF-5000 Series Install Manual 265
AF-6600 / AF-5000 Series Post Installation Check
CAUTION: Do not fly the aircraft until the following check list has been completed.
Never Power the system with an automotive battery charger and the aircraft battery
disconnected.
Before Power is applied for the First Time
□ Screen mounted following the installation manual
□ ADAHRS mounted (Label up, Pitot-Static fittings forward)
□ Wiring harness is properly connected to screen
□ Verify relay protection diodes are installed on all large aircraft relays (Master, Starter,
Avionics...etc)
□ Pitot/Static and AOA plumbing is secured to the correct SV-ADAHRS ports
□ Trim Servo indication wires are connected per the installation manual wiring diagram
Applying Power for the First Time
□ Turn on aircraft Master Battery switch to power on the EFIS screens.
□ Verify the unit powers on.
□ Set the clock time-zone offset
□ Set the AHRS Pitch Adjust for your aircraft's panel tilt (0 to 7 degrees typically)
□ Following the installation manual, calibrate the Fuel Tanks
□ Following the installation manual, calibrate all trim and flap position sensors
□ Set the airspeed V speeds based on your aircraft manufacturers
recommendations.
□ Set all engine temperatures/limits based on your engine manufacturers
recommendations
□ Set fuel tank, fuel pressure, fuel pressure, oil temperature, and oil pressure warning
parameters
□ Configure your Serial Ports based on devices connected
□ Configure your GPS/NAV Settings based on Serial Port selection
□ Verify all GPS and NAV sources are properly communicating with the EFIS. See
Appendix J: 430W - EFIS - Autpilot - ARINC Troubleshooting guide if you have an
autopilot and/or a Garmin GNS-430W/530W.
□ AOA Post-Installation Pre-Flight Checklist Completed
First Engine Start
□ With relay protection diodes installed, your AFS screen(s) can be turned on before the engine is
started.
