Version 16.10 AF-6600 AF-5000 Series Install Manual 173
Aircraft Info Menu
The following items should be configured in the Aircraft Info menu:
1. Weight & Balance – Select Aircraft Model
2. Engine Type – Select Engine
3. Tail Number – Enter Aircraft Tail Number
4. Mode S Code – For N Number registered aircraft the EFIS will calculate, you will need to enter the
Mode S code for non N number aircraft.
