Version 16.10 AF-6600 AF-5000 Series Install Manual 239
APPENDIX F: Database Updates
The AF-6600 / AF-5000 series store the Map data on the internal EFIS memory, the Approach Plates, VFR
Sectionals, IFR Low Maps and Airport diagrams are stored on a USB memory stick plugged into the back of
the EFIS or panel mounted USB extension.
Seattle Avionics Dynon Skyview Chart Data
Chart data provided by Seattle Avionics is updated on the EFIS USB memory stick using the Seattle
Avionics Chart Data Manager PC software. Each EFIS display in the aircraft must have a separate USB
stick with the data plugged into the rear USB connector.
Seattle Avionics Data is available from the following link:
http://seattleavionics.com
Map Nav Data
The AF-6600 / AF-5000 series can use Map NAV data provided by:
1. AFS NAV data for USA Customers (Free from AFS web site)
See next page for instructions.
2. Jeppesen NAV Data for different regions in the world (Purchased from Jeppesen web site)
3. Pocket FMS NAV Data for different regions in the world (Purchased from Pocket FMS web site)
