Version 16.10 AF-6600 AF-5000 Series Install Manual 51
CO Guardian Display
The AF-5000 will display data from any of the CO Guardian units
that support RS-232 MFD output. The current cabin CO level is
displayed on any of the Check List pages. If the CO Guardian
device generates a warning, the current CO level will be
displayed as a pop up message on the EFIS screen. If you have
the new Aero-455 (CO, heart rate, O2 level ) monitor, the data
will be displayed as a pop up message after about 20 seconds
of monitoring you finger. The CO Guardian should be wired to
any open serial port and then the serial port Admin setting set to
CO Guardian.
