Version 16.10 AF-6600 AF-5000 Series Install Manual 50
Post Installation Checks
• Verify buttons operate all AP modes.
• Verify dim commands from EFIS display dim the backlighting of the SV-AP-PANEL.
• Verify that trim controls operate as commanded from Pilot and (optional) Copilot controls.
• During a test flight, use the PITCH trim pushbuttons to bring the plane slightly out of PITCH
trim. Verify that PITCH auto-trim automatically trims the PITCH as needed. (Assumes that
PITCH auto-trim is enabled.)
• During a test flight, use the ROLL trim pushbuttons to bring the plane slightly out of ROLL trim.
Verify that ROLL auto-trim automatically trims the ROLL as needed. (Assumes that ROLL auto-
trim is enabled.)
