Version 16.10 AF-6600 AF-5000 Series Install Manual 185
Outside Air Temp (OAT)
The EFIS OAT display comes from the OAT sensor wired to each ADAHRS. With a dual ADAHRS install
you will have two separate OAT probes. The Configure OAT menu will display the temperature from each
ADAHRS temperature sensor.
2. Display Units Celsius or Fahrenheit
6. OAT Adjust (degF) Temperature Offset ADAHRS 1
10. OAT Adjust (degF) Temperature Offset ADAHRS 2
