Version 16.10 AF-6600 AF-5000 Series Install Manual 210
Exhaust Gas Temp (EGT)
1. Select the correct Thermocouple Type that matches the EGT temperature transducer installed on the
engine.
Dynon ships K-TYPE EGT Probes in their Sensor Kits.
3. Verify the EGT Temperature gauge display ranges match your engine manufacturers recommendations.
Current temperature readings for each connected EGT probe.
The number of cylinders displayed is controlled by the Engine Type setting in the Configure Aircraft Info.
