Version 16.10 AF-6600 AF-5000 Series Install Manual 179
Yaw Damper
The Yaw Damper in-flight calibration procedure is covered in the AF-6600 / AF-5000 Pilots Guide.
The following calibration items should be configured before doing the in-flight tuning.
1. Instrument ON/OFF Turns ON or OFF the Yaw Damper
2. Advanced Tuning Mode OFF
3. Servo Calibration See next section for instructions
4. Servo Test See next section for instructions
5. Torque 100%
To Next Page
